YORK IWE Modular Chiller – YVAG Series
Global Cynax proudly introduces the YORK YVAG Series Air-Cooled DC Inverter Chiller , an advanced solution for energy-efficient cooling and heating. Capacity ranges from 3TR to 11TR, the YORK YVAG Series is designed for residential and light commercial applications. It offers superior energy efficiency, quiet operation, and a wide operating range, making it ideal for diverse climates. Unlike traditional VRF systems, it uses a hydronic loop, reducing refrigerant use and simplifying maintenance. With modular scalability, smart controls, and pre-equipped components, the YVAG ensures cost-effective installation and seamless adaptability to evolving needs, delivering reliable comfort and sustainability year-round.
The YORK YVAG Series Chillers deliver unmatched performance with advanced DC inverter compressor technology and variable frequency drive for optimized energy use, achieving EER up to 3.63 and IPLV (C) up to 5.0. They operate efficiently in diverse climates, offering cooling in temperatures from -5°C to 48°C and heating water up to 58°C, ideal for underfloor heating. With a compact, modular design supporting up to 4 units and built-in hydronic components, they simplify installation while scaling capacities from 11.2 kW to 160 kW. Quiet operation is ensured with dual brushless DC fans and Silent Mode, while smart controls integrate seamlessly with Building Automation Systems (BAS). Reliability is enhanced by automatic fault detection and future-proof adaptability, making them a robust choice for various applications.
Technical Specification
| Feature | Details |
|---|---|
| Models Available | YVAG012RSE, YVAG014RSE, YVAG016RSE, YVAG018RSE, YVAG020RNE, YVAG022RNE, YVAG025RSE, YVAG028RSE, YVAG033RSE, YVAG040RSE |
| Cooling Capacity (Nominal) | Ranges from 11.2 kW (YVAG012RSE) to 40 kW (YVAG040RSE) |
| Heating Capacity (Nominal) | Ranges from 12.6 kW (YVAG012RSE) to 42 kW (YVAG040RSE) |
| Energy Efficiency | - EER: Up to 3.63 (YVAG020RSE) - IPLV (C): Up to 5.0 |
| Compressor Type | High-efficiency rotary DC inverter compressors |
| Cooling Power Input | Varies from 3.8 kW to 13.3 kW |
| Heating Power Input | Varies from 3.8 kW to 12.7 kW |
| Fan Motor | Brushless DC Fan Motor |
| Sound Pressure Level | - Minimum: 54 dB(A) (YVAG012RSE) - Maximum: 62 dB(A) (YVAG040RSE) |
| Water Flow Rate | Nominal flow ranges from 1.93 m³/h to 6.88 m³/h, depending on the model |
| External Head Pressure | From 11m (YVAG018RSE) to 22m (YVAG020RSE) |
| Expansion Tank Volume | From 2 liters to 8 liters |
| Operating Ranges | - Cooling: -5°C to 48°C - Heating: -27°C to 43°C |
| Water Temperature Range | - Cooling: 12/7°C leaving temperature - Heating: Up to 58°C for radiant panels or underfloor heating |
| Modular Capability | Combine up to 4 units for a total capacity of 160 kW |
| Dimensions (LxWxH) | - Varies by model (e.g., YVAG012: 995x360x1320 mm; YVAG040: 1300x760x1700 mm) |
| Weight | - Lightest: 126 kg (YVAG012RSE) - Heaviest: 350 kg (YVAG040RSE) |
| Power Supply | - Single-phase: 220V-1Ph-50Hz - Three-phase: 380/400V-3Ph-50Hz |
The YORK IWE Modular Chiller is an excellent solution for Bangladesh, offering advanced cooling technology with exceptional reliability, energy efficiency, and scalability to meet projects of any size. As the authorized distributor of Johnson Controls for YORK Chillers, Global Cynax delivers complete turnkey HVAC solutions, covering everything from initial design to seamless project implementation.
Global Cynax ensures comprehensive support, including warranty services, after-sales assistance, spare parts supply, and technical support provided by a team of skilled engineers.
For an efficient and dependable cooling solution tailored to your space, contact us today and let our expertise meet your requirements!
